Tube en acier WT24mm ASTM 500 de rectangle sans couture d'ERW
ContPerson : Richard SHEN
Numéro de téléphone : +86-13736164628
WhatsApp : +8613736164628
Quantité de commande min : | 0,5 tonnes | Prix : | negotiable |
---|---|---|---|
Détails d'emballage : | Par paquets | Délai de livraison : | 5-8 jours de semaines |
Conditions de paiement : | L/C, T/T | Capacité d'approvisionnement : | 60000tons par an |
Lieu d'origine: | LA CHINE | Nom de marque: | Torich |
---|---|---|---|
Certification: | IS09001 ISO14001 TS16949 | Numéro de modèle: | ASTM B163 |
Détail Infomation |
|||
Norme: | ASTM B163 | Matériel: | N06025 |
---|---|---|---|
OD: | 12.0-76.2mm | poids: | 0.5-12.0mm |
longueur: | 12M maximum | Application: | Échangeur de chaleur |
Surligner: | Tube d'alliage de nickel N06025,Tube d'alliage de nickel de WT1.5mm,Tuyau d'alliage de nickel N06025 |
Description de produit
Tube d'alliage de nickel pour l'échangeur de chaleur
Détail rapide :
Taille :
OD : 1/2 « -3 » 12.0-76.2mm
POIDS : 0,02" - 0,5" 0.5-12.0mm
Longueur : Pi 105ft 32 32mt
Tuyau : NPS1/2 » +-6 » 21.34-168.3mm
POIDS : Sch10-Sch80
POIDS : 2.11-12.7mm
Longueur 45ft 14mt
Méthode de production : Étiré à froid et laminé à froid
Application : Échangeur de chaleur, énergie nucléaire, ingénieur mécanicien.
Matériel : Inconel 600 Inconel 625, INCOLOY 617, INCOLOY 800/H
Composition chimique :
Conditions chimiques
Élément | N06025 | N06045 | N06600 | N06601 | N06603 | N06617 | N06674 | N06690 | N06693 | N06696 |
Ni | reste | 45.0min | 72.0min | 58.0-63.0 | reste | 44.5min | reste | 58.0min | reste | reste |
Cr | 24.0-26.0 | 26.0-29.0 | 14.0-17.0 | 21.0-25.0 | 24.0-26.0 | 20.0-24.0 | 21.5-24.5 | 27.0-31.0 | 27.0-31.0 | 28.0-32.0 |
Fer | 8.0-11.0 | 21.0-25.0 | 6.0-10.0 | reste | 8.0-11.0 | 3.0max | 20.0-27.0 | 7.0-11.0 | 2.5-6.0 | 2.0-6.0 |
Manganèse | 0.15max | 1.0max | 1.0max | 1.5max | 0.15max | 1.0max | 1.50max | 0.5max | 1.0max | 1.0max |
MOIS | … | … | … | … | … | 8.0-10.0 | … | … | … | 1.0-3.0 |
Co | … | … | … | … | … | 10.0-15.0 | … | … | … | … |
Al | 1.8-2.4 | … | … | 1.0-1.7 | 2.4-3.0 | 0.8-1.5 | … | … | 2.5-4.0 | … |
C | 0.15-0.25 | 0.05-0.12 | 0.15max | 0.10max | 0.20-0.40 | 0.05-0.15 | 0.10max | 0.05max | 0.15max | 0.15max |
Cu | 0.1max | 0.3max | 0.5max | 1.0max | 0.50max | 0.5max | … | 0.5max | 0.5max | 1.5-3.0 |
B | … | … | … | … | … | 0.006max | 0.0005-0.006 | … | … | … |
SI | 0.5max | 2.5-3.0 | 0.5max | 0.5max | 0.50max | 1.0max | 1.0max | 0.5max | 0.5max | 1.0-2.5 |
S | 0.010max | 0.010max | 0.015max | 0.015max | 0.010max | 0.015max | 0.015max | 0.015max | 0.01max | 0.010max |
Ti | 0.1-0.2 | … | … | … | 0.1-0.25 | 0.6max | 0.05-0.20 | … | 1.0max | 1.0max |
NOTA: | … | … | … | … | … | … | 0.10-0.35 | … | 0.5-2.5 | … |
P | 0.020max | 0.020max | … | … | 0.020max | … | 0.030max | … | … | … |
Zr | 0.01-0.10 | … | … | … | 0.01-0.10 | … | … | … | … | … |
Y | 0.05-0.12 | … | … | … | 0.01-0.15 | … | … | … | … | … |
Ce | … | 0.03-0.09 | … | … | … | … | … | … | … | … |
N | … | … | … | … | … | … | 0.02max | … | … | … |
W | … | … | … | … | … | … | 6.0-8.0 | … | … | … |
