heat exchanger tubes
"
ASTM A179 3/4" étiré à froid standard tubes d'échangeur de chaleur 14BWG
ASTM A179 3/4' 14BWG Heat Exchanger Tube Standard ASTM A179 Matrial 10# 20# etc Carbon Steel Size OD: 12.7-177.8mm WT: 1-25.4mm Length: according to customer requirement Application For Boilers,Superheaters, Heat-Exchangers, High-pressure Boilers Production Tubes are manufactured by seamless process and both hot finished and cold finished are applicable Heat treatment Hot finished tubes need not be heat treated. Cold Finished tubes are heat treated after the final cold
Tubes sans couture d'échangeur de chaleur SUS304 d'ASTM A213
TORICH ASTM A213 304 19.05x1.65 Heat Exchanger Tubes What kind of coiled tubing we can produce? unit:mm OD 4.76 WT 0.51 0.71 0.89 1.24 OD 6 WT 1 1.5 OD 6.35 WT 0.51 0.71 0.89 1.24 1.65 OD 7.94 WT 0.71 0.89 1.24 1.65 OD 9.53 WT 0.71 0.89 1.24 1.65 OD 10 WT 1 1.5 2 OD 12 WT 1 1.5 OD 12.7 WT 0.71 0.89 1.24 1.65 OD 14 WT 1 1.5 2 OD 15.88 WT 0.71 0.89 1.24 1.65 2.11 OD 16 WT 1 1.5 2 OD 19.05 WT 1 1.24 1.65 2.11 OD 25.4 WT 1.24 1.65 2.11 2.54 OD 31.8 WT 1.24 1.65 2.11 2.54 OD 38.1
Tubes sans couture d'échangeur de chaleur de l'acier inoxydable Tp321 d'Astm A213
ASTM A213 Seamless Stainless Steel Heat Exchanger Tubes Bright annealed stainless steel tubes as per following standard: ASTM A213 ASTM A269 EN10216-5 TC-1 Tolerance:D4/T3 (±0.5%,±0.1 min)/(±10%,±0.2 min) NDT Tests:Eddy Current or Hydraulic Test or UT Heat treatment on tubes: Bright Annealed stainless seamless tube Quality Assurance: ISO 9001&PED 97/23/EC certificated with 100% traceability on all instrument tubes and material test reports(EN 10204/3.1B)accompany every
Tubes standard étirés à froid d'échangeur de chaleur d'OD 12.7mm Astm A179
ASTM A179 Cold Drawn Heat Exchanger Tubes Advantages of tubular heat exchanger: fast heat exchange, high temperature resistance (400 ℃) and high pressure resistance (2.5MPa). Compact structure, small floor area, light weight, convenient installation and saving civil engineering investment. It has flexible design, complete specifications, strong practicability and pertinence, and saves money. Wide application conditions, suitable for large pressure, temperature range and heat
Tubes d'échangeur de chaleur d'Astm A178 Q195 de chaudière, tuyau sans couture étiré à froid
Tube Boiler ASTM A178 Heat Exchanger Tubes Material: Carbon steel and carbon manganese steel Production: Electric Resistance Welding Size range: O.D.: 12.7-127mm W.T.:0.9-9.1mm L: according to customer requirement Applications: For Boilers, Superheaters, Heat-Exchangers, Condensers, Boiler flues, Superheater flues and e ends Heat treatment: After welding, all tubes are heat treated at a temperature of 1650℉ (900℃) or higher and followed by cooling in air or in the cooling
Le condensateur de tubes d'échangeur de chaleur d'acier au carbone d'Erw siffle Astm A214 Sa214
ASTM A214 SA214 ERW Carbon Steel Heat-Exchanger Tubes Condenser Pipes Size range: O.D.:6-76.mm W.T.:0.9-19.0mm L: according to customer requirement Manufacture: Tubes are made by electric-resistance welding. Steel Grade and Chemical Compositions: C 0.18 Mn 0.27 to 0.63 P ≤0.035 S ≤0.035 Hardness Requirements: The tubes shall have a hardness number not exceeding 72HRB. Surface Condition: The finished tubes are free of scale., slight amount of oxidation is not considered as
Tubes d'échangeur de chaleur de l'acier au carbone 1mm d'ASTM A179
ASTM A179 Carbon Steel Heat Exchanger Tubes Applications: for Boilers,Superheaters,Steam linepipes of boilers Size range: O.D.:12.7-127mm W.T.:1-15mm L: according to customer requirement Steel Grade and Chemical Compositions: Grade C Mn P S Si A-1 ≤0.27 ≤0.93 ≤0.035 ≤0.035 ≥0.10 C ≤0.35 0.29-1.06 ≤0.035 ≤0.035 ≥0.10 Mechanical properties: Grade Yield Point Mpa(ksi) Tensile Strength Mpa(ksi) Elongation A-1 ≥255(37) ≥415(60) ≥30% C ≥275(40) ≥485(70) ≥30% Tolerance for OD and WT
Tubes d'échangeur de chaleur de l'acier au carbone TORICH d'ASTM A192
ASTM A192 Carbon Steel Heat Exchanger Tubes Applications: for Boilers,Superheaters,Steam linepipes of boilers Size range: O.D.:12.7-127mm W.T.:1-15mm L: according to customer requirement Steel Grade and Chemical Compositions: Grade C Mn P S Si A-1 ≤0.27 ≤0.93 ≤0.035 ≤0.035 ≥0.10 C ≤0.35 0.29-1.06 ≤0.035 ≤0.035 ≥0.10 Mechanical properties: Grade Yield Point Mpa(ksi) Tensile Strength Mpa(ksi) Elongation A-1 ≥255(37) ≥415(60) ≥30% C ≥275(40) ≥485(70) ≥30% Tolerance for OD and WT
Tubes rayés d'échangeur de chaleur du poids 13.5mm d'OD 63.5mm X
OD63.5XWT13.5 Rifled Pipe Heat Exchanger Tubes Product Name:OD63.5XWT13.5 Rifled Pipe Heat Exchanger Tubes Material Carbon steel,Alloy steel Od: 21.3-762mm: Standard DIN GB ISO JIS BA ANSI Grade: 20G,20MnG,15CrMoG,SA210Gr.A1, SA210Gr.C, SA213T12, ASTM A335P11 P91,P22,16Mo3....... Wall thickness: 2.77-25.4mm Length: 5.8/6/11.8/12mtr as required or random length Thread No.: 4ribs/6ribs/8ribs/12ribs...... Surface treatment: Black painting, oiled or galvanized Payment term; 30%
