YB/T 4370 Tubes en acier inoxydable soudés Tubes en acier inoxydable pour le transport de gaz urbain
ContPerson : Richard SHEN
Numéro de téléphone : +86-13736164628
WhatsApp : +8613736164628
Quantité de commande min : | 5 tonnes | Prix : | negotiable |
---|---|---|---|
Détails d'emballage : | Emballé dans la boîte en bois ou sur demande | Délai de livraison : | 30-60days après a reçu votre paiement |
Capacité d'approvisionnement : | 5,000tons par an |
Lieu d'origine: | La Chine | Nom de marque: | TORICH |
---|---|---|---|
Certification: | ISO 9001 ISO14001 TS 16949 GL PED RINA | Numéro de modèle: | JIS G3459 |
Détail Infomation |
|||
Nom du produit: | La soudure de JIS G 3459 et les tuyaux d'acier inoxydables austénitiques sans couture pour la pressi | la norme: | JIS G3459 |
---|---|---|---|
Matériau: | Acier inoxydable austénitique | Qualité: | SUS304TP SUS310TP SUS316TP SUS317TP SUS347TP etc. |
Application: | Pour le but de pression | Méthode de production: | Soudure à l'arc électrique, soudure laser sans couture ERW |
Norme appropriée: | KS D 3576 ASTM A 312 A376 DIN 17455 DIN 17456 BS3605 BS 4127 | Forme: | Round |
Surligner: | acier en forme de tuyau inoxydable,tube d'acier inoxydable de grand diamètre |
Description de produit
La soudure de JIS G 3459 et les tuyaux d'acier inoxydables austénitiques sans couture pour la pression purpose
Épaisseur de paroi : 0.5-50mm
Diamètre : 5-420mm
Longueur : Sur demande
Catégorie :
SUS304TP, SUS304HTP, SUS304LTP,
SUS310TP, SUS310STP,
SUS316TP, SUS316HTP, SUS316LTP, SUS316TiTP,
SUS317TP, SUS317LTP,
SUS347TP, SUS347LTP
Application :
pour le but de pression, pour le service de basse température, service à hautes températures
Méthode de produit :
Traitement thermique :
COMPOSITION CHIMIQUE % maximum |
|||||||||
catégorie en acier |
composition chimique |
||||||||
|
C |
SI |
Manganèse |
P |
S |
Ni |
Cr |
MOIS |
d'autres |
SUS304TP |
0,080 |
1,00 |
2,00 |
0,045 |
0,030 |
8.00-11.00 |
18.00-20.00 |
- |
- |
SUS304HTP |
0.04-0.10 |
0,75 |
2,00 |
0,040 |
0,030 |
8.00-11.00 |
18.00-20.00 |
- |
- |
SUS304LTP |
0,030 |
1,00 |
2,00 |
0,045 |
0,030 |
9.00-13.00 |
18.00-20.00 |
- |
- |
SUS310TP |
0,150 |
1,50 |
2,00 |
0,040 |
0,030 |
19.00-22.00 |
24.00-26.00 |
- |
- |
SUS310STP |
0,080 |
1,50 |
2,00 |
0,045 |
0,030 |
19.00-22.00 |
24.00-26.00 |
- |
- |
SUS316TP |
0,080 |
1,000 |
2,00 |
0,045 |
0,030 |
10.00-14.00 |
16.00-18.00 |
2.00-3.00 |
- |
SUS316HTP |
0.04-0.10 |
0,750 |
2,00 |
0,030 |
0,030 |
11.00-14.00 |
16.00-18.00 |
2.00-3.00 |
- |
SUS316LTP |
0,030 |
1,00 |
2,00 |
0,045 |
0,030 |
12.00-16.00 |
16.00-18.00 |
2.00-3.00 |
- |
SUS316TiTP |
0,080 |
1,00 |
2,00 |
0,045 |
0,030 |
10.00-14.00 |
16.00-18.00 |
2.00-3.00 |
Minute de Ti5*C% |
SUS317TP |
0,080 |
1,00 |
2,00 |
0,045 |
0,030 |
11.00-15.00 |
18.00-20.00 |
3.00-4.00 |
- |
SUS317LTP |
0,030 |
1,00 |
2,00 |
0,045 |
0,030 |
11.00-15.00 |
18.00-20.00 |
3.00-4.00 |
- |
SUS347TP |
0,080 |
1,00 |
2,00 |
0,045 |
0,030 |
9.00-13.00 |
17.00-19.00 |
- |
Minute de NOTA: 10*C% |
SUS347LTP |
0.04-0.10 |
1,00 |
2,00 |
0,030 |
0,030 |
9.00-13.00 |
17.00-20.00 |
- |
NOTA: 8*C%-1.00 |
PROPRIÉTÉS MÉCANIQUES minimum |
|||
Catégorie en acier |
MPA de résistance à la traction |
MPA de limite élastique ou d'effort de preuve |
Élongation % |
SUS304TP |
520 |
205 |
35 |
SUS304HTP |
520 |
205 |
35 |
SUS304LTP |
480 |
175 |
35 |
SUS310TP |
520 |
205 |
35 |
SUS310STP |
520 |
205 |
35 |
SUS316TP |
520 |
205 |
35 |
SUS316HTP |
520 |
205 |
35 |
SUS316LTP |
480 |
175 |
35 |
SUS316TiTP |
520 |
205 |
35 |
SUS317TP |
520 |
205 |
35 |
SUS317LTP |
480 |
175 |
35 |
SUS347TP |
520 |
205 |
35 |
SUS347HTP |
520 |
205 |
35 |
