Tube en acier inoxydable

Austenitic Stainless Small Diameter Seamless Steel Tubes GB/T 3090 Spec: Material:SUS 304/316 ASTM 304/316/321 EN 1.4301/1.4541/1.4404 etc Size Range:OD:0.4-12mm WT:0.1-2mm General Length:0.5-4m Tolerance: According to the following tables or customers’ request. Chemical composition Steel grade Chemical composition,% C Si Mn P S Ni Cr Mo Ti 0Cr18Ni9 ≤0.07 ≤1.00 ≤2.00 ≤0.035 ≤0.030 8.00~11.00 17.00~19.00 — — 00Cr19Ni10 ≤0.03 ≤1.00 ≤2.00 ≤0.035 ≤0.030 8.00~12.00 18.00~20.00 — —

ISO 2037 Stainless steel tubes for the food industry Application: In food industry Materials: Austenitic stainless steels shall be used. - Seamless tubes: TS47, TS60 and TS61 in accordance with ISO 2604-6:1978 - Weld tubes: TW 47, TW 60 and TW61 in accordance with ISO 2604-4:1978 Surface roughness: The surface roughness in accordance with the specifications of ISO 468 Fine surface finish Ra ≤ 1 μm Other surface finish Ra ≤ 2.5 μm Table 1 Dimension in millimeters Tube outside

Medical And Small Diameter Tubing Standard ASTM A270, ASTM A554, A249, A269, A312 Matrial 201 ( Ni 1.2%), 202 (Ni 3.5%~4.5%), 301(Ni 5%), 304 (Ni 8%, Cr 18%),316 (Ni 10%, Cr 18%), 316L (Ni10%~14%), 430 Size OD: 0.4mm--8.0mm WT: 0.05mm - 0.9mm Length: According to Customer's Requirement Common size 0.4*0.11, 0.5*0.1, 0.5*0.15, 0.6*0.1, 0.6*0.125, 0.63*0.15, 0.7*0.1, 0.7*0.15, 0.8*0.1, 0 .8*0.125, 0.8*0.15, 0.9*0.1, 0.9*0.15 etc Surface Finish 180G, 320G, 400G Satin / Hairline

Capillary Tubes Bright Annealed Stainless Steel Tube Precision Stainless Steel Tubing with Super Small Diameter 0.08-1.0 Outside Diameter : OD 0.28-10mm Thickness : 0.08-1mm Production Process: Cold Drawn Bright Anneal etc Type : Seamless,welded Surface : Pickling, Bright; Price Item : EXW,FOB,CNF,CIF etc Application 1). Heat exahanger tube for petrochemical,chemical and ocean development 2). Industrial furnace and heater tubes 3). for gas turbine and prochemical processing4)

ASTM A269 Cold Drawn Welded and SeamlessTube Small Diameter Medical Tubes TorichInternational Co.,Ltd is a professional manufacturer and exporter of steel pipes materials. It is an international marketing and sales company specialized in steel tubes. Our main products:Seamless Steel Tubes with Carbon and Alloy Steel Grade, Welded Precision Steel Tubes,DOM Steel Tubes, Seamless & Welded Stainless Steel Tubes with Nickel and Alloy Steel Tube. Our factory was established since

201 304 316 316L MEDICAL SMALL DIAMETER STAINLESS CAPILLARY STEEL TUBE DETAILS ABOUT THE CAPILLARY TUBE Material 304, 201, 304L, 316, 316L, or as customer's request Standard ASTM, AISI, GB, JIS, as customers' request OD 0.5-10mm W.T 0.02-2.5mm Length customize Sample Free sample is available Tolerance ±0.02mm Application Decorations Constructions Food industry, medical industry etc. Finish Options Polished Normal #400-#500 #600 Mirror #700-#800 Brushed Round lines Straight

Product Description TORICH 316 304 Medical Sanitary Food Grade Pipe Welded Small Diameter Thin Wall Round Seamless Stainless Steel Capillary Tube Standard ASTM A554, A249, A269 and A270, A312 Matrial 201 ( Ni 1.2%), 202 (Ni 3.5%~4.5%), 301(Ni 5%), 304 (Ni 8%, Cr 18%), 316 (Ni 10%, Cr 18%), 316L (Ni10%~14%), 430 Size OD: 0.5mm--8mm WT: 0.08mm - 2mm Length: According to Customer's Requirement Surface Finish 180G, 320G, 400G Satin / Hairline 400G, 500G, 600G or 800G Mirror

TORICH 316 304 Medical Sanitary Food Grade Pipe Welded Small Diameter Thin Wall Round Stainless Steel Capillary Tube Commodity name Small diameter bright annealing welded stainless steel capillary tube Process method Welded Stainless steel grades TP304/304L, TP310/S,TP316/316L, TP317L, TP321, TP347/H S31803/2205, 904L Standard ASTM A213, A312, A511, A270, A269, A789, A790, DIN17456, DIN17458, JIS G3463 Size 6 x 0.3 ..... Testing Chemical Analysis. Hydrostatic or Nondestructiv

High Quality Seamless Stainless Steel Tubes with small Diameter from TORICH Product information Product name High Quality Small Diameter Stainless Steel Tubes with Competitive Price from TORICH!! OD 10~820mm WT 0.2~52.37mm,Sizes can be customized Length Less than 12m Standard GB12771-91, ASTM A1053/A1053M-06, ASTM A268/A268M-05A, ASTM A269-07,ASTM A270-03A, ASTM A312/A312M-06, ASTM A358/A358M-05, ASTM A632-04,ASTM A789/A789M-05b, ASTM A790/A790M-05b, ASTM A872/A872M-07A, ASTM
