tuyauterie lourde d'acier de mur

ASTM 1020 SMALL DIAMETER THICK WALL SEAMLESS STEEL PIPE AISI 1020 Carbon Seamless Steel Pipe Tube Chemical Composition(%) Mechanical Property C Si Mn S P Cr Ni Cu Mo Yield Strength Tensile Strength ( σs ) ( σb ) 0.18~0.23 0.15-0.35 0.30~0.60 ≤0.050 ≤0.040 ≤0.25 ≤0.25 ≤0.25 - ≥414 (MPa) ≥483 (MPa) End Shape Beveled end, plain end, vanished, or adding plastic caps to protect the two ends as per customer's requirements Surface Oiled, Galvanized, Phosphate etc Treatment Technique

TORICH Seamless Carbon Mild 300mm Large Diameter ST37 15Mo3 High Pressure 4 Inch C45 Heavyr-caliber Heavy Thick Wall Steel Pipe Size Range: OD:20-300mm WT: 5-50mm Length: Max 12000mm Characteristic: Good OD and ID tolerance controlled to Technical Standard Stable quality Tolerances: OD: D 5 – 10 mm: ± 0.15 mm D 11 – 30 mm: ± 0.30 mm D 32 – 50 mm: ± 0.40 mm D 51 – 140 mm: ± 0.8% WT: S 0.4 – 1 mm: ± 0.12 mm S 1.2 – 5 mm: ± 10% S 5.5 – 12 mm: ± 8% Notes: 1. Steel grades: 10, 20,

EN10216-1 100mm Wall Thickness Heavy Wall Steel Tubing Round Steel Pipe Standard: EN10216-1 Seamless steel tubes for pressure purposes-Technical delivery conditions Non-alloy steel tubes with specified room temperature properties Applications: for manufacturing pipelines, vessel. Euqipment.pipt fittings and steel structure Size range: O.D.:10.2-711mm W.T.:1-100mm L:max12000mm Chemical composition Steel Grade C Si Mn P S Cr Mo Steel Name Steel Number max max max max max max

API 5CT 2" 4" API J55-API P110 Thick Wall 4130 Chromoly Alloy Steel Pipe Size 15*15-400*400mm 30*20-400*200mm Wall Tickess 0.5mm-16mm Length 1m-12m ,or by customer’s requirements International Standard ISO 9001-2008 Standards ASTM A53,BS1387-1985,GB/T3091-2001,GB/T13793-92, GB/T6728-2002 Materials Q195,Q215,Q235,Q345 4310 kinds of alloy steel pipe Product Category Metallurgy, Mineral & Energy Technique Welded Packing 1.Big OD: in bulk vessel 2.Small OD: packed by steel strips

DIN EN 10210-1 Hot Finished Heavy Wall Steel Tubing Thick Wall Steel Pipe For Manufacturing Pipelines Material The material used for DIN EN 10210-1 hot finished heavy wall steel tubing and thick wall steel pipes is commonly known as structural steel. It is specifically designed for use in the construction industry, where high strength and durability are required. Structural steel is known for its excellent ability to withstand heavy loads and its suitability for various

Heavy Wall Steel Tubing Hot Finished Thick Wall Steel Tube EN 10210 For Manufacturing Pipelines Material and Specification Material EN 10210 Hot Finished Structural Hollow Sections Type Heavy Wall Steel Tubing Size Range Outer Diameter: 168.3 - 914.4 mm Wall Thickness: 10 - 120 mm Length 6 - 18 meters Standards EN 10210 Process Hot Finished Chemical Composition Element Composition (%) C (Carbon) 0.22 (max) Si (Silicon) 0.55 (max) Mn (Manganese) 1.6 (max) P (Phosphorus) 0.03

TORICH 1045/1020 Heavy Wall Tubing Cold Drawn Seamless Precision Cutting Tube Used for Manufacturing Nuts Standard: ASTM A519, Seamless circular steel tubes for mechanical and general engineering purposes - Technical delivery conditions Non-alloy and alloy steel tubes Application: for seamless circular tubes made of non-alloy and alloy steels for mechanical and gneral engineering purposes. Size range: O.D.: 5-420mm W.T.: 0.5-50mm L:max12000mm Material: 1008,1010,1020,1026

TORICH Seamless Carbon Mild 300mm Large Diameter ST37 15Mo3 High Pressure 4 Inch C45 Heavyr-caliber Heavy Thick Wall Steel Pipe 1.Quick Detail: 45 1045 S45C SCM440 42CrMo Thick wall tubes for sleeve. High Mechanical properties Reasonable price Material High quaity 45# 16Mn 35# 20# 10# 40Cr 20Cr 20CrMo 20CrMnTi 40MnMoV 42CrMo 10Mn2 15Cr 30CrMnSi Stanard GB/T8162 8163 ASTM A500 ASTM A501 JIS G3441 JIS G3444 ASTM A53 DIN1629 GOST8734-75 and others Tolerance The common difference

Process Method : cold drawn and cold rolled Out Diameter : 6-711mm Wall Thickness : 0.5-40mm Length : 6-25 meters Steel Grade : 200 (Ni : 0.8%), 201B (Ni : 3%), 201H (Ni : 5%) 301 (Ni : 6%), 304, TP304, TP304L/304L, 321, TP321, 316, TP316L, 316L, 316Ti 317, 317L, 309S, 310S(2520), 347, Duplex 2205, Duplex 2207, etc. Specification Packing 1.with plastic cap to protect both ends 2.plastic bag wrapped outside the pipe 3.bundles to be covered by polythene & strapped securely . 4
