tubes et tuyaux sans soudure, en acier

JIS G 3445 STKM 11A Seamless CS pipes OD13mm x WT3.2mm,OD 8mm x ID5.1mm for Hyundai, Maruthi, Nissan, Caterpiller etc 1. Standard: JIS G3445 Standard STKM 11A high precision seamless steel tube 2. Steel Grade: STKM11A STKM12A STKM12B STKM12C STKM13A STKM13B STKM13C STKM14A STKM14B STKM14C STKM15A STKM15C STKM16A STKM16C STKM17A STKM17C STKM18A STKM18B STKM18C STKM19A STKM19C STKM20A 3. Production method: Cold drawing on the seamless steel tubes, to reach high accuracy on the

Precision Cold Drawn Seamless Steel Tube Used for Mechanical Purpose Standard: ASTM A519, Seamless circular steel tubes for mechanical and general engineering purposes - Technical delivery conditions Non-alloy and alloy steel tubes Application: for seamless circular tubes made of non-alloy and alloy steels for mechanical and gneral engineering purposes. Size range: O.D.: 5-420mm W.T.: 0.5-50mm L:max12000mm Material: 1008,1010,1020,1026,1045,4130,4140, E235, E275, E315, E355,

ASTM A519 EN10305-1 Cold Drawn Precision Seamless Pipe For Hydraulic System Quick Detail: Cold Drawn Seamless Precision steel pipes for Hydraulic system OD:4-420 (mm) WT0.5-80(mm) Length 1000-12000mm Steel Grade: E215, E235, E355 Product name: S Cold Drawn Seamless Precision Steel Pipe Application: for hydraulic systems Precision Steel Pipes for Hydraulic System- Standard Size Chart OD (mm) WT (mm) Length (mm) 4 0.5 5800-6000 4.0 1.0 5800-6000 5.0 1.0 5800-6000 6.0 1.0 5800

EN10305-4 E235 +N Carbon Steel Seamless Precision Hydraulic Tube,6*1.0,8*1.5,10*1.5,16*1.5,25*3.0 1. Standard: EN10305-4 Cold drawn Precision Seamless Steel Pipes 2. Steel Grade: E215,E235,E355, other materials upon agreement with customers. 3. Production method: Cold drawing on the seamless steel tubes, to reach high accuracy on the OD and WT tolerance, with certain heat treatment to achieve better mechanical properties for bending and pressure purposes 4. Size range: O.D.:5

ASTM A179 Seamless Steel Tube For High Pressure Service for Boiler Size: Outer Diameter: 6-1000 mm,Wall Thickness: 1- 80 mm,Length :1-12m or as your request Application:Manufacture of Feedwater Heater Material:10#.20#.16Mn.A106(B,C).ST35-ST52 Manufacture :Tubes shall be made by the seamlessprocess and shall be cold drawn. Heat Treatment: 1)Cold-drawn tubes shall be heat treated after the finalcold-draw pass at a temperature of 1 200F [640C] or higher toensure ductility satis

Omega Shaped Seamless Pipe / Cold Drawn Seamless Steel Tube For Pressure Machinery Product information: Material: SAE1010 , SAE1020 , SAE1035 , SAE1045 , ST37.0 , ST44 , ST52 , E235 , E355 Grade: BS, JIS, GB, DIN, ASTM, API, Shape: Lemon Wall thickness: 0.5-50mm Length: up to 12m, or according to customer's requirement. Outer diameter: Round: 5-420mm Diameter and wall thickness could be at customer's request. Technology: Cold Draw/Cold Rolled Surface treatment: painted

EN10305-1/ASTM A513 Cold Drawn Heavy Wall Mechanical Seamless Honed Tube Standard: ASTM A513 Grade Group: A53-A369 Thickness: 0.5 - 50 mm Outer Diameter(Round): 5 - 420 mm Surface Treatment: Bright Technique: Cold Drawn, Cold Drawing Material: SAE1010,SAE1020,SAE1026,SAE4130,SAE4140 L: max12000mm 1. ASTM A519 Oil cylinder Seamless Carbon and Alloy Steel Mechanical Tubing 2. Steel Grade: SAE1010,SAE1020,SAE1026,SAE4130,SAE4140 3. Porudction Method: Cold drawing + Honing +

Carbon Tube Information Name CrMo 4130 seamless steel bicycle cold drawn pipe Out Diameter 30-250mm Wall Thickness 2-30mm Material A53, A106, ST52, E355, STKM11A, STK,13A, CK45, S45C Delivery Condition Cold Drawn/Cold Rolled/Honed/Stress Relieved Delivery Time within 45 days after receiving prepayment Trade Term FOB, CIF, CFR or as client's request Payment Term TT, LC, or as client's request Cold Drawn Steel Tube Cold Drawn Steel Tube, or Cold Rolled Steel Tube, usually help

ASTM B135 C27000 C27200 H58 Seamless Brass Round Tube ASTM B135 C27000 C27200 Seamless Brass Round Tube Application: residential housing water pipes, heating, cooling pipes installed aviation, aerospace,ships, military industry, metallurgy, electronics, electrical, mechanical, transportation,construction and other fields of the national economy. Size Range: OD: 2-914mm WT: 0.2-120mm Length: 2m,4m,5.8m,6m,12m or per customer’s request Material: Grade: C27000 C27200 Chemical
